CP7782-SP6 Chicago Pneumatic #5 Spline Drive Impact Wrench 1,920 Ft

Designed for tire changing applications, this 1" impact wrench with its high torque of 1,920 ft.lbs is highly recommended. The pinless closed reinforced rocking dog impact mechanism and metal housing offer high durability.

The spline drive design creates less play between the anvil and the socket, resulting in more power and longer life of the socket.Technical SpecificationsImperialMetricTorqueMax working torque fwd1480 ft.lbfMax torque reverse1920 ft.lbfMin working torque fwd369 ft.lbfTorque limitedNoAir informationAir consumption at load40 cfmAir inlet thread size (in)1/2Max dynamic air working pressure90 psiMin hose diam (16 ft hose length)0.5 inNoise & vibrationsSound Power111 dB(A)Sound Pressure100 dB(A)Uncertainty vibration-K5.9 ft/s²Vibration (m/s²)7.8Vibration25.6 ft/s²SpeedFree Speed5200 rpmSize & WeightLength (L)22.44 inPower weight ratio250 Nm/kgWeight25.5 lbDesign & FunctionsBlow per minute500BodyAluminumClutch housingAluminumClutch lubrication typeGreaseHandle typeD-handleImpact mechanismPinless rocking dogMain Material typeAluminumOutput drive size (in)#5 SplineOutput drive type#5 SplineOutput retainer typeFriction ringSide handleYesStarting systemTrigger
